2S-072-005 Dapol J72 0-6-0 68745 BR Black Early Crest

Add To Comparison

2S-072-005 Dapol J72 0-6-0 68745 BR Black Early Crest

New release - pre-orders invited - expected during 4th Quarter 2025. preauthkernow

History

First built in 1898 as a smaller wheel shunting variant of the successful J71 class, the J72 continued to be built with minor changes over the next 53 years. In 1937 two of the class were fitted with vacuum braking to work as carriage shunters and more followed from 1947 onwards, eventually leading to 41 members of the class being so fitted. Several of the vacuum brake fitted locomotives were repainted in lined passenger liveries by both the LNER and British Railways for use as station pilots. Locomotives so painted were generally keep very clean by shed staff and crews. The 113 members of the class all continued their sterling work until the first locomotive was withdrawn in 1958. The final locomotive was withdrawn out of normal service in 1964 but two were transferred to Departmental Stock, one of these locomotives lasted in this role until 1967. One member of the class, number 69023 is preserved.

General Specification

This locomotive was developed using many original GA drawings to ensure a high level of accuracy of these models. Due to the tiny size of the model, many of the larger components are diecast to ensure the locomotive weighs as much as possible. In addition to this, the centre driving wheels will be sprung, and the coreless motor is fitted with a flywheel to help overcome dead frogs while performing shunting duties.

Body

  • Diecast footplate
  • Diecast tanks
  • NER tapered buffers
  • LNER “Group Standard” buffers
  • NER wheel and handle smokebox door locking
  • Later, LNER two handle style smokebox door locking
  • Vacuum brake equipment for locomotives so fitted
  • Smokebox numberplate for B.R. period
  • Ross Pop safety valves
  • NER style “trumpet” safety valve cover



Chassis

  • Diecast chassis – split frames for live bearing pickup
  • Blackened nickel plated driving wheels
  • Brass bearings
  • Plastic keeper plate with brake shoe/linkage details
  • Sprung centre driving wheels
  • Wheels to NMRA standards



Electrical

  • Pickup from all six driving wheels
  • Coreless motor
  • Flywheel
  • Provision for Next-18 Decoder in cab
  • Access for decoder fitting via four screws
  • Direct springing to centre driving wheel bearings to ensure electrical contact

    Details specific to this version

  • Accessory Pack
  • NEM Coupling
  • NER Tall Chimney
  • NER Buffers
  • NER Trumpet Safety Valves
  • Smokebox Door Numberplate
  • LNER Smokebox Door Dart
  • Rear Spectacle Coal Guards



Name:
2S-072-005 Dapol J72 0-6-0 68745 BR Black Early Crest
DCC Status:
Next 18 Pin Socket
Gauge:
N Gauge
Price:
£ 119.00 Saving £21.00 (15.00%) on RRP (£140.00)
Product Code:
COK002
Availability:
Non-Stock Item (Special Order).
Stock Level:
0
