PECO SETRACK N GAUGE
The complete range of N Gauge Peco Setrack - essential for building your N Gauge layout.
Peco N gauge Setrack is a Code 80 rigid unit track system designed with standardised geometric increments so curves, straights, and turnouts easily snap together into parallel loops.
Key Track Dimensions & Radii
- Standard Straight (ST-1): 87 mm (3.5 in) long
- Short Straight (ST-2): 58 mm long
- Double Straight (ST-11): 174 mm (6.78 in) long
- 1st Radius Curve (ST-3 / ST-12): 228 mm (9 in) radius (8 pieces per full circle)
- 2nd Radius Curve (ST-15): 263.5 mm (10.375 in) radius (8 pieces per full circle)
- 3rd Radius Curve: 298.5 mm (11.75 in) radius
- 4th Radius Curve (ST-19): 333.4 mm (13.125 in) radius (8 pieces make a semi-circle)
Turnouts and Geometry Compatibility
- Turnouts (Points): Standard Setrack turnouts generally feature a 22.5-degree turnout angle, built with an over-centre spring for manual or immediate use without extra lever hardware.
- Crossings: Specialized matching crossings (such as ST-50 and ST-51 short/standard crossings) integrate directly with the turnout geometry.
- Streamline Integration: Peco N Setrack is fully compatible with Peco Streamline Code 80 and Code 55 track, allowing components to transition smoothly as your layout expands beyond fixed geometry.
